RNAO Needle Roller Bearings

Home>> Needle Roller Bearings>>Needle Roller Bearings >> RNAO Needle Roller Bearings

RNAO Needle Roller Bearings

RNAO Needle Roller Bearings

Drawing

Datasheet

Bearing No.	Dimensions			Mass	Bearing No.	Dimensions			Mass
Bearing No.	Fw	D	C		Bearing No.	Fw	D	C
–	mm	mm	mm	kg	–	mm	mm	mm	kg
RNAO 5x10x8	5	10	8	0.003	RNAO 35x45x17	35	45	17	0.069
RNAO 6x13x8	6	13	8	0.006	RNAO 35x45x26	35	45	26	0.091
RNAO 7x14x8	7	14	8	0.006	RNAO 35x47x16	35	47	16	0.078
RNAO 8x15x10	8	15	10	0.008	RNAO 35x47x18	35	47	18	0.076
RNAO 10x17x10	10	17	10	0.01	RNAO 35x47x32	35	47	32	0.16
RNAO 12x22x12	12	22	12	0.019	RNAO 40x50x17	40	50	17	0.074
RNAO 15x23x13	15	23	13	0.02	RNAO 40x50x34	40	50	34	0.15
RNAO 16x24x13	16	24	13	0.021	RNAO 40x55x20	40	55	20	0.15
RNAO 16x28x12	16	28	12	0.032	RNAO 40x55x40	40	55	40	0.28
RNAO 17x25x13	17	25	13	0.022	RNAO 45x55x17	45	55	17	0.083
RNAO 18x30x24	18	30	24	0.069	RNAO 45x62x40	45	62	40	0.38
RNAO 20x28x13	20	28	13	0.025	RNAO 50x62x20	50	62	20	0.14
RNAO 20x28x26	20	28	26	0.05	RNAO 50x65x20	50	65	20	0.17
RNAO 20x32x12	20	32	12	0.038	RNAO 50x65x40	50	65	40	0.36
RNAO 22x30x13	22	30	13	0.027	RNAO 55x68x20	55	68	20	0.17
RNAO 22x35x16	22	35	16	0.059	RNAO 60x78x20	60	78	20	0.26
RNAO 25x35x17	25	35	17	0.053	RNAO 60x78x40	60	78	40	0.44
RNAO 25x35x26	25	35	26	0.076	RNAO 65x85x30	65	85	30	0.46
RNAO 25x37x16	25	37	16	0.06	RNAO 70x90x30	70	90	30	0.5
RNAO 30x40x17	30	40	17	0.06	RNAO 80x100x30	80	100	30	0.58
RNAO 30x42x16	30	42	16	0.059	RNAO 90x105x26	90	105	26	0.37
RNAO 30x42x32	30	42	32	0.14	RNAO 90x110x30	90	110	30	0.61
RNAO 35x45x13	35	45	13	0.059	RNAO 100x120x30	100	120	30	0.69
